10 Meyer Sound M’elodie Self-Powered Line Array Loudspeaker

Meyer Sound M’elodie Self-Powered Line Array Loudspeaker

Meyer Sound M’elodie is an ultracompact, high-power, self-powered curvilinear array loudspeaker designed for professional sound reinforcement. It combines impressive output, consistent coverage and the trusted sonic performance associated with Meyer Sound in a compact touring enclosure.

The Meyer Sound M’elodie is an excellent solution for concerts, theaters, festivals, houses of worship, corporate productions, nightclubs, live-event venues and professional rental companies. Its compact size makes it especially useful in venues where space and visual impact are important, while its integrated amplification simplifies installation and touring system setup.

These used Meyer Sound M’elodie loudspeakers are available in excellent working condition. Each unit has been professionally inspected and tested to confirm that the drivers, internal amplifier, signal connections and protection systems operate correctly.

Minor cosmetic signs of normal professional use may be visible, but they do not affect the performance of the loudspeakers. Additional photographs, serial-number pictures and operating videos can be provided to serious buyers upon request.

Powerful Performance in an Ultracompact Cabinet

The Meyer Sound M’elodie was designed to provide professional line-array performance without the size and weight associated with many larger touring systems. Each cabinet contains two high-power 8-inch low-frequency cone drivers and one high-frequency compression driver coupled to a constant-directivity horn.

The two 8-inch drivers work together at lower frequencies to produce strong low-frequency and low-mid output. At midrange frequencies, the system’s processing controls the drivers to maintain consistent directional performance and reduce unwanted interference.

The high-frequency section provides clarity for vocals, instruments and detailed program material. Its design helps the loudspeaker maintain consistent horizontal coverage across the listening area.

The recommended operating frequency range extends from approximately 70 Hz to 18 kHz. For applications requiring deeper bass, the system can be combined with compatible Meyer Sound subwoofers.

Self-Powered Three-Channel Amplification

One of the most important advantages of the Meyer Sound M’elodie is its self-powered design. Every cabinet contains an integrated three-channel Class AB/H amplifier, eliminating the need for separate external power amplifiers.

The internal amplifier provides a total burst output of approximately 1,275 watts, with a peak output of 2,550 watts. Two amplifier channels power the low-frequency and low-mid-frequency drivers, while a separate channel powers the high-frequency driver.

Because the amplifier, processing and transducers were designed to operate as one complete system, users do not need to calculate amplifier matching or create external crossover settings for the individual components.

The self-powered architecture can also reduce the amount of equipment required in an amplifier rack. This makes transportation, setup and system troubleshooting more straightforward for touring companies and event-production teams.

Integrated Processing and Driver Protection

The Meyer Sound M’elodie includes internal processing for equalization, phase correction, crossover functions and driver protection. These features help the loudspeaker deliver reliable and consistent performance under demanding professional conditions.

The crossover between the low-frequency and high-frequency sections is approximately 1,100 Hz. The two 8-inch drivers operate together between approximately 70 Hz and 320 Hz. Above that range, one driver continues through the midrange to maintain appropriate directional characteristics.

Integrated protection helps prevent damage caused by excessive input levels while preserving the musical character of the signal. However, correct system design, gain structure and electrical distribution remain essential when operating any professional sound system.

The loudspeaker also supports Meyer Sound’s RMS remote-monitoring system. When used with compatible monitoring equipment, technicians can observe important operating information from connected loudspeakers.

Consistent Coverage for Professional Venues

Each Meyer Sound M’elodie cabinet provides approximately 100 degrees of horizontal coverage. Vertical coverage depends on the number of cabinets and the splay angles selected between them.

Multiple cabinets can be arranged to create an array that matches the shape and seating layout of a venue. Smaller splay angles can provide longer projection, while wider angles can increase vertical coverage for closer audience areas.

Correct array design is important for obtaining uniform sound pressure and tonal balance. The number of cabinets required will depend on the venue dimensions, audience capacity, trim height, desired sound-pressure level and type of program material.

Professional system prediction and experienced rigging personnel are recommended for flown installations. All configurations must follow Meyer Sound’s official rigging instructions and applicable local safety requirements.

QuickFly Professional Rigging System

The Meyer Sound M’elodie uses integrated QuickFly rigging with captive GuideALinks. This system allows cabinets to be connected with adjustable splay angles between zero and 11 degrees.

The integrated rigging system supports both flown arrays and properly configured ground-stacked systems. Compatible accessories include the MG-M’elodie multipurpose grid, MCF-M’elodie caster frame and MTF-MICA/M’elodie transition frame.

The multipurpose grid can be used for flying or ground stacking. The caster frame allows groups of cabinets to be transported while remaining connected, helping reduce setup time at touring events.

Only original, compatible and properly inspected rigging equipment should be used. Rigging should always be handled by qualified professionals who understand load calculations, local regulations and overhead-suspension safety.

Compact Size and Touring Construction

The cabinet is constructed from premium birch plywood and finished with a durable black textured coating. A powder-coated steel grille protects the front-mounted components during transportation and use.

Each cabinet measures approximately:

* Width: 28.54 inches or 724.84 mm
* Height: 9.19 inches or 233.31 mm
* Depth: 12.75 inches or 323.85 mm
* Weight: 62 pounds or 28.12 kg

The relatively compact dimensions make the system suitable for venues where larger line-array cabinets may be impractical. Its size also allows touring companies to transport multiple cabinets efficiently.

Protective covers, caster frames and suitable transport cases are recommended for equipment that will be moved regularly.

Flexible Power and Signal Connections

The Meyer Sound M’elodie accepts a balanced analog audio signal through professional XLR input and loop-through connections. The loop output allows the audio signal to be distributed to additional cabinets in the array.

Depending on the model and production configuration, AC connections may use PowerCON input and loop output or a VEAM all-in-one connection. Buyers should verify the exact connector type shown on the rear panel before purchasing power or signal cabling.

The internal power supply supports professional international operating voltages. Nevertheless, customers should confirm the voltage configuration, connector type and local electrical requirements before using the equipment.

Electrical distribution for a large array should be planned by a qualified technician. The system must be correctly grounded and protected with suitable power distribution.

Applications for Meyer Sound M’elodie

The Meyer Sound M’elodie is suitable for many professional sound applications, including:

* Concerts and live music productions
* Corporate events and conferences
* Theaters and performing arts centers
* Churches and houses of worship
* Nightclubs and entertainment venues
* Professional touring productions
* Festivals and outdoor events
* Television and broadcast productions
* AV rental company inventories
* Permanent venue installations

The compact cabinet is particularly useful when high-quality sound and controlled coverage are required without using a physically large array.

Compatible Subwoofers and System Processing

Although the Meyer Sound M’elodie can reproduce frequencies down to approximately 70 Hz, professional music systems normally benefit from dedicated subwoofers.

Compatible Meyer Sound subwoofers may include the 500-HP, 600-HP or 700-HP, depending on system size, availability and the intended application. The correct subwoofer ratio will depend on the music style and required low-frequency output.

A Meyer Sound Galileo loudspeaker-management system can provide system equalization, delay, routing, level control and alignment between the main arrays, subwoofers and fill loudspeakers.

System technicians should use suitable measurement and prediction tools when configuring a complete system. Correct alignment between the main loudspeakers and subwoofers can improve impact, frequency response and consistency throughout the venue.

Condition and Professional Testing

These used Meyer Sound M’elodie loudspeakers are in excellent working condition with no known operational issues. Every unit is tested before sale.

The inspection process includes checking:

* Low-frequency drivers
* High-frequency driver
* Internal amplifier operation
* Audio input and loop output
* AC power connection
* Cabinet and protective grille
* Integrated rigging components
* Normal operation at professional listening levels

Because these are used professional loudspeakers, reasonable cosmetic wear may be present. Buyers should examine the product photographs and request additional images when necessary.

The availability of rigging grids, caster frames, protective covers, power cables and signal cables should be confirmed before ordering.

What Is Included?

The standard sale includes the Meyer Sound M’elodie loudspeaker and the available compatible power cable.

Depending on the selected package, additional equipment may include:

* Meyer Sound M’elodie loudspeakers
* Compatible power cables
* Signal-linking cables
* MCF-M’elodie caster frames
* MG-M’elodie rigging grids
* Protective covers
* Associated rigging hardware
* Meyer Sound subwoofers
* Galileo system processor

Only accessories specifically listed on the final quotation or invoice should be considered included.

Worldwide Shipping Available

Worldwide shipping is available for the Meyer Sound M’elodie. Equipment can be securely prepared for domestic or international transportation.

Shipping costs depend on the quantity, destination, packaging method and required delivery service. Larger systems may require palletized freight shipping.

Customers should provide the following information to receive a complete quotation:

* Number of loudspeakers required
* Complete delivery address
* Postal code
* Country
* Company or customer name
* Telephone number
* Required accessories

Local pickup or equipment inspection may also be arranged by appointment when available.

Why Choose Meyer Sound M’elodie?

The Meyer Sound M’elodie remains a practical option for buyers seeking a compact, professional self-powered line-array system. It combines high acoustic output, wide horizontal coverage, integrated amplification, onboard processing and professional rigging in a manageable enclosure.

Its advantages include:

* Compact professional line-array design
* Two high-power 8-inch drivers
* Integrated three-channel amplification
* Approximately 1,275 watts of burst output
* Up to 2,550 watts peak output
* 70 Hz to 18 kHz operating range
* Up to 131 dB peak SPL
* 100-degree horizontal coverage
* Integrated processing and protection
* QuickFly rigging hardware
* RMS remote-monitoring compatibility
* Durable birch-plywood cabinet

Contact https://soundprotech.shop/today for current availability, package pricing, additional photographs and a shipping quotation for the Meyer Sound M’elodie.
